2022 BRITAIN STANDARD LED CRICKET SCOREBOARD
| Brand | Linger |
| Type No. | LCS-19D300Y |
| Board Size | 2100mm L * 1300mm H * 90mm T |
| Color Option | Red,Green,White, Blue ,Yellow |
| Digit Height | 12inch 300mm |
| LED Type | Mist Led Diodes and It's no Dazzling |
| Digit Type | Completely PCB Circuit Board With DIP Led Diodes |
| Power Supply | AC110V ~ 240V , 50-60Hz |
| Control Model | Wireless Controller Box |
| Communication Type | Wire / Wireless |
| Mounting /Installation | Brackets for Hanging / Tripod / Holder / Moving Stand |
| Front Face | 5mm Acrylic Panel + Inkjet Printing Film |
| Frame Color | Black or Any Color (Option) |
| Acrylic Lens | Best Quality and Non- Reflective |
| Power Plug | UK,Europe,China,Australia,USA,etc.. |
| Whole Product | Completely Silent Operation and Minimal Generated |
| Waterproof | IP65 |
| View Distance | 1m ~ 200m |
| Communication Distance | 1m ~ 100m (Wire) / 1m ~ 250m (Wireless) |
| Brightness | > 7500mcd / m2 |
| Life Span | 100000 Hours |
| Net Weight | 30KGS/M2 |
| Adv.Power | < 150W |
| Warranty | 12 Months |
1. Test the Leds Chrominance and Angle in darkroom
( Using Equipment : Light Source Analysis System)
2. Test the Temperature and Humidity
(Using Equipment : High – Low Temp. & Variation Chamber)
3. Test the Seismic Performance
(Using Equipment : Transportation Vibration Testing Machine)
4.Test the waterproofing performance and long-term ponding water.
(Using Equipment : Splash Water Test Equipment )
5. Passed all above Testing ,product will be aging at least for
72Hours.
(Aging Method : Light the all leds and to be Flashing )
1. We are manufacturing company and engaged in LED Scoreboard for
11 years.
2. The Yellow Color is best for brightness in day and night. Best
Option for outdoor use .
3. The digits are DIP type ,not the cheap Segment tube .We use
twice number of leds than other companies.
4. Front Face with 5mm thickness Acrylic Glass Board with UV
Protection (Not the PC board)
5. 8'' digit with 102pcs of diodes
6. The cabinet is Waterproof and IP 65 (Front) IP54 (Rear)
7. The warranty is 2 Years.
