Multi - Sports Electronic Score Boards for Basketball Sport in
Single Red color
| PRODUCT INFORMATION |
| Model No. : | LG-LBS-15D200RG300Y |
| Dight Height and Color : | 8'' 200mm Height in Red / Yellow / Green Color |
| Display Dimension : | 3.9 ft x 6.6 ft ( 1200mm x 2000mm x 100mm ) |
| Operation Type : | PVC Buttons Type Controller Box / Windows Software (Wireless) |
| View Distance : | 1m ~ 300m |
| Application : | Basketball Game |
| Frame Color : | Black / other Colors |
| Printed Letters | Sticker in White Color |
| Brightness : | > 5000mcd / sqm |
| Waterproof : | Outdoor Type |
Basketball Scoreboard Descripition
Function : Display Basketball Game Score and Information.
Specification :
1) Use of the environment: Indoor or Outdoor
2) Brightness: High Level Brightness
3) Height of Characte: 8'' 200mm
4) Display Led Color : Red / Green / Yellow (Any other kind is
Option)
5) Frame Color : Green Color (Any other kind is Option)
Overall Structure :
1) Display usage: 15 Pieces digits ,8 inch and 12 inch character
in Three Colors
2) Frame : Iron / Steel
3) Faceplate : Display window cover glass board and UV Protection
4) Drainage Outlet at the bottom of the Frame
5) Fans install inside of scoreboard
Technical Norms :
1) Power Supply : 110V ~ 240V
2) Operation Circumstance: -30℃ ~ 65℃ ,0% ~ 95% relative humidity
Operation Type :
1) PVC Buttons Controller Box / Windows Software
2) Hard - wire / Wireless Type
3) Operation Distance : Max 1000Meters.
4) Controller box works by 110V ~ 240V Power (Battery is an Option)
Life Time of Leds : 100000 Hours
Installation : Hanging / Mounting / Custoized Design
Delivery Time : 7days ~ 12days
Warranty : 2 Years
Package Dimension : 1070mm x 2070mm x 160mm (Carton)
Screen Dimension : 3.9 ' x 6.6 ' x 4''
Function
Game Time :
1) 4-Digits to Display : MM : SS
2) Countdown / Count Up / Day Time is Option
3) Set time by Controller with Buttons for MIN +1 -1 , SEC +1 -1
Team Score :
1) Time Out : 1 digit display number 0 - 9
2) Fouls : 1 digit display number 0 - 9
3)Home and Away Scores : 3digits display number from 000 - 999
Period : 1 Digits display number 0 - 9
Subs / Arrows : On / Off
Siren : With Siren ,when time reach to 00 : 00 ,it will sound for
5''
Led Brightness : Option
SCOREBOARD FUNCTION IS CUSTOMIZED ,ANY FUNCTION IS WELCOME !
Scoreboard Design Details
1. To finish the scoreboard Layout drawing, or can send us the
photo of the scoreboard you need to
produce.
2. On the website we display a lot of Sport Scoreboards for
different games.To Select the similar
scoreboard picture and send us your idea or changes for this one.
3. After we talking about the all design details and changes ,new
confirmed scoreboard layout will be send
to confirm.
4. For the scoreboard size and Color ,the digit height and color
,all are negotiated.
5. To plus or reduce the digit on the scoreboard,make different
color in one scoreboard,make different
color for cabinet , print Logo on the scoreboard ,all requests are
available in the layout drawing.
FAQ
Q1. What is your payment ?
A : We accept T/T , Wester Union , Paypal.
Q2. When can you arrange the shipment after i have placed an order
?
A : Usually about 10days after receiving Payment.
Q3. Can you accept customized ?
YES.Welcome!
Q4. Is it OK to print my logo on the product?
A : Yes. Please inform us formally before our production and
confirm.
Purchase Process
1. Inquiry-Professional quotation by email or telephone. 2. Confirm
the price, lead time, artwork, payment term etc. 3. Send the
Performa Invoice. 4. Customer makes the payment and sends us Bank
receipt. 5. Initial Production Stage-Inform the clients that we
have got the payment, And will make the samples according to your
request, send you photos or Samples to get your approval. After
approval, we inform that we will arrange the production & inform
the estimated time. 6. Middle Production-send photos to show the
production line which you can see your products in . Confirm the
estimated delivery time again. 7. End Production-Mass production
products photos and samples will send to you for approval. You can
also arrange the third party inspection if you need. 8. Finish the
balance payment if the order has .Book the flight or vessel and
ship the goods. Inform the tracking number or send the Documents
for Customer to do Customs Clearance. 9. Order can be say “finish”
when you receive the goods and satisfy with them. 10. Feedback to
us about Quality, Service, Market Feedback & Suggestion. And we can
do better.
