Regular 12inch 300mm Digit Height Electronic Digital LED Cricket
Scoreboard with Brackets
| PRODUCT INFORMATION |
| Model No. : | LG-LCS-19D300R |
| Dight Height and Color : | 12''300mm in Single Red Color |
| Display Dimension : | Large One : 4ft x 6.9ft ( 1200mm * 2100mm * 100mm ) |
| Operation Type : | PVC Buttons Type Controller Box / Windows Software (Wireless) |
| View Distance : | 1m ~ 250m |
| Application : | Cricket Game |
| Frame Color : | Black / Red / Green / Blue / White / Grey / Others |
| Printed Letters | Sticker in White Color / Others Color |
| FOB Port : | Shanghai |
| H.S Code : | 8531200000 |
| Frame Material : | Iron / Steel |
Descripition of the Cricket Scoreboard
Function : Display Score
Specification :
1) Use of the environment: Outdoor
2) Brightness: High Level Brightness
3) Height of Characte: 12'' 300mm for main scoreboard
4) Display Color : Red Color (Any other kind is Option)
5) Frame Color : Black Color (Any other kind is Option)
6) Bottom Line is Moving Message Sign in Amber Color
Overall Structure :
1) Display usage: Totally 19 pieces digits ,12 inch height
characte
2) Frame : Iron / Steel
3) Faceplate : Display window cover glass board and UV Protection
4) Drainage Outlet at the bottom of the Frame
5) Fans install inside of scoreboard
Technical Norms :
1) Power Supply : 110V ~ 240V
2) Operation Circumstance: -30℃ ~ 65℃ ; 0% ~ 95% relative humidity
Operation Type :
1) PVC Buttons Controller Box / Windows Software
2) Hard - wire / Wireless Type
3) Operation Distance : Max 1000Meters.
4) Controller box works by 110V ~ 240V Power (Battery is an Option)
Life Time of Leds : 100000 Hours
Installation : Hanging / Mounting / Custoized Design
Delivery Time : 7days ~ 12days
FOB Port : Shanghai
Warranty : 2 Years
Package Dimension : 1170mm x 1770mm x 150mm (Carton)
Screen Dimension : 4' x 6.9' x 4''
Function
BAT No. 1 : 1digit to display number from 0 - 9
BAT No. 2 : 1digit to display number from 0 - 9
RUNS 1 : 3digits to display number from 000 - 999
RUNS 2 : 3digits to display number from 000 - 999
TOTAL : 3digits to display number from 000 - 999
OVERS : 2digits to display number from 00 - 99
WKTS : 1digit to display number from 0 - 9
1st INNS : 3digits to display number from 000 - 999
Sticker in white Color on the Scoreboard can be any Letters.
Function Option : Brightness Adjust / Clear Score
Any Special Function is Welcome !
FAQ
Are you a manufacture?
A : Yes, we are a manufacture with rich experience.
Can I visit your factory ?
A : Welcome ! The nearest air port is Shanghai Pudong International
Airport.
How does your factory do Quality Control?
A : Quality is 1st priority. We always attach great importance to
quality controlling from
raw material suppliers. We have professional QC team to inspect the
products.
Can you add my own LOGO on the product?
A : Yes, customized logo are welcome. OEM and ODM is OK for us.
Can we use our own shipping agent?
A : Yes, you can. We had cooperated with many forwarders. If you
need ,we can
recommend some forwarders to you and you can compare the price and
services.
Q1: What should I do if my Scoreboard is not working properly?
Check the Input Power is with right Volatge. Some countries use
110V and Some Countried use 220V.
If the controller box is without Battery. That must be a power
cable to connect to 110V / 220V plug.
Any other problem can contact with us and take photos for us to
check .
Q2: What is the correct way to store the scoreboard ?
1. Keep out of the reach of children under 8 years.
2. Do not store in dampness and high temperature places.
3. Avoid direct sunlight.
Q3 : What about the maintaince for the scoreboard ?
2 Years Warranty .
Under the condition of not artificial damage, we will send you the
new parts to replace.
1. Do you accept OEM & ODM order?
Yes! We can produce products according to customers’ design and
samples.
2. What is MOQ?
MOQ can be 1unit.
3. How about the payment terms?
T/T ,Western Union,Paypal in advance .
4. Can I get samples from you?
Yes! Sample could be supplied. But it is not free.
5. What is the warranty?
It is 2 years.
6. What about the price level?
As a professional manufacturer who have been Specializing in the
production of led scoreboard,led gas
price sign,led message sign,led disply for more than 15years, we
are sure that our prices have a great
competitive advantage over the products at the same level.
