Low Current Electronic Portable Digital Cricket Scoreboard for
College
| PRODUCT INFORMATION |
| Model No. : | LG-LCS-9D300Y |
| Dight Height and Color : | 12'' 300mm in Single Amber Color |
| Display Dimension : | 3.6ft x 5.6ft ( 1100mm * 1700mm * 100mm ) |
| Operation Type : | PVC Buttons Type Controller Box / Windows Software (Wireless) |
| View Distance : | 1m ~ 300m |
| Application : | Cricket Game |
| Frame Color : | Black / others |
| Printed Letters | Sticker in White Color |
| Brightness : | > 5000mcd / sqm |
| Waterproof : | Outdoor Type |
| Frame Material : | Iron / Steel |
| Viewing Angle : | >110° |
Feature
Function : Display Score
Specification :
1) Use of the environment: Outdoor
2) Brightness: High Level Brightness
3) Height of Characte: 12'' 300mm
4) Display Color : Red Color (Any other kind is Option)
5) Frame Color : Black Color (Any other kind is Option)
Overall Structure :
1) Display usage: Totally 9 pieces digits ,12 inch height
character
2) Frame : Iron / Steel
3) Faceplate : Display window cover glass board and UV Protection
4) Drainage Outlet at the bottom of the Frame
5) Fans install inside of scoreboard
Technical Norms :
1) Power Supply : 110V ~ 240V
2) Operation Circumstance: -30℃ ~ 65℃ ; 0% ~ 95% relative humidity
Operation Type :
1) PVC Buttons Controller Box / Windows Software
2) Hard - wire / Wireless Type
3) Operation Distance : Max 1000Meters.
4) Controller box works by 110V ~ 240V Power (Battery is an Option)
Life Time of Leds : 100000 Hours
Installation : Hanging / Mounting / Custoized Design
Delivery Time : 7days ~ 12days
Warranty : 2 Years
Package Dimension : 1170mm x 1770mm x 150mm (Carton)
Screen Dimension : 3.6' x 5.6' x 4''
1. Linger devote to design the different sports of customized
scoreboard, any kind of digit height and digit color is made for
different scoreboard.
2. Scoreboard controller type can be with cable or wireless type.
3. The brightness is enough for outside in day and night.
4. Scoreboard with Iron waterproof cabinet and prevent the impact.
5. The front face is acrylic glass board to protect digits and the
acrylic glass board is UV Protection type.
Function
TOTAL : 3digits to display number from 000 - 999 / Buttons for
TOTAL + 1 + 5 - 1
OVERS : 2digits to display number from 00 - 99 / Buttons for OVERS
+ 1 - 1
WKTS : 1digit to display number from 0 - 9 / Buttons for WKTS + 1 -
1
1st INNS : 3digits to display number from 000 - 999 / Buttons for
1st INNS + 1 + 5 - 1
Sticker in white Color on the Scoreboard can be any Letters.
Function Option : Brightness Adjust / Clear Score
Any Special Function is Welcome !
1) Hard - Wire Controller with cable .
2) Sponsor Panel Graphics or Text information.
3) 12v Rechargable battery power pack with 240v inverter
4)
Pair of Electronic Batsman Name Displays (200mm, 8-10 digits)
Pair of Electronic Batsman Name Displays (300mm, 8-10 digits)
Pair of Electronic Batsman Name Displays (400mm, 8-10 digits)
Pair of Electronic Batsman Name Displays (500mm, 8-10 digits)
5)
Single Line VMS text/sponsor/message display (300mm)
Single Line VMS text/sponsor/message display (400mm)
Single Line VMS text/sponsor/message display (500mm)
6) 10 Year Extended Warranty
7) Mobile Trolley on Pneumatic Wheels
1. We manufactured Led Product over 10 Years.Rich experience with
excellent staff, first-class production
environment ,rigorous and efficient enterprise management system.
2. Customized Design Product is welcome.And MOQ can be 1 Unit.We
will provide the competition price
for Various Led Products.
3. The company has a variety of test equipment to control product
quality like “Light Source Analysis
System”, “High – Low Temp & Variation Chamber”, “Transportation
Vibration Testing Machine”, “Splash
Water Test Equipment” .
4. Flexible Payment – Wire Transfer (T/T), Wester Union, Paypal .
5. Products all certificated, all our products have passed all
test, certification can be provided if you need.
Packing and Logistics
1. Where do you load the goods?
We offer shipment by sea or by air as requested by the buyer. The
sea port we are used : Shanghai Sea port The airport we are used :
Shanghai Airport
2. What is the lead time ?
Usually, the lead time is 7-10 days. 3. Which logistics company do you cooperate with? Our company cooperates with COSCO, APL, CMA, CSAV, K-LINE, MSC and
etc. For courier, it’s up to buyer’s option. We will give
suggestion according to the time table of the steamers and their
services.
