1m x 2m Size and Red Color 12inch Digits Led Electronic Board for
Semi - Outdoor
| PRODUCT INFORMATION |
| Item No. : | LG-LFS200R-8D-VTN-2 |
| Dight Height and Color : | 8'' 200mm Height in Red Color |
| Scoreboard Dimension : | 2.6ft x 4.6ft (800mm*1400mm*90mm) |
| Team Name Height and Color: | P12mm Module in Red Color |
| Team Name Size : | 96mm x 576mm x 2 Names |
| Controller Type : | PVC Controller Box / Windows Software (Wireless) |
| View Distance : | 1m ~ 200m |
| Application : | Multi - Sports |
| Work Temperature : | -20℃ ~ 60℃ |
| Humidity : | 0% - 95% |
Description
Function : Used for Multi - Sport and display GAME TIME,TEAM NAME, 2 Teams
SCORE
Specification :
1) Use of the environment: Indoor or Outdoor
2) Brightness: High Level Brightness
3) Height of Characte: 8'' 200mm
4) Display Led Color : Red (Any other kind is Option)
5) Frame Color : Black Color (Any other kind is Option)
Overall Structure :
1) Display usage: 8 Pieces digits , 8 inch character in Red Color
6 Pieces Module ,P12mm in Red Color
2) Frame : Iron / Steel
3) Faceplate : Display window cover glass board and UV Protection
4) Drainage Outlet at the bottom of the Frame
5) Fans install inside of scoreboard
Technical Norms :
1) Power Supply : 110V ~ 240V
2) Operation Circumstance: -30℃ ~ 65℃ ,0% ~ 95% relative humidity
Operation Type :
1) PVC Buttons Controller Box / Windows Software
2) Hard - wire / Wireless Type
3) Operation Distance : Max 1000Meters.
4) Controller box works by 110V ~ 240V Power (Battery is an Option)
Life Time of Leds : 100000 Hours
Installation : Hanging / Mounting / Custoized Design
Delivery Time : 7days ~ 12days
Warranty : 2 Years
Package Dimension : 870mm x 1470mm x 160mm (Carton)
Screen Dimension : 2.6 ' x 4.6 ' x 4''
Function
Scoreboard can used for Football Game or Netball Game . The digit
height is 200mm and in Red Color.
Controller Box is PVC material with buttons. Install Wireless
Module and operation Distance is 1m ~ 200m.
1) GAME TIME : 4Digits - MM : SS -00 : 00 ~ 99 : 59
2) TEAM 1 : 2Digits - 00 ~ 99
3) TEAM 2 : 2Digits - 00 ~ 99
4) TEAM NAME : Pitch12mm Red Modules , Max 6 Letters for each team
name.
5) GAME TIME Type : Countdown / Count up
6) With Siren. When the time to be 00 : 00 or reach to Setup Time,
the siren will sound for 5 Seconds.
7) Team Name : Enter A - Z letter by Controller Buttons
About the Scoreboard function ,it is customized . Any request is
welcome.
Scoreboard Design Details
1. To finish the scoreboard Layout drawing, or can send us the
photo of the scoreboard you need to
produce.
2. On the website we display a lot of Sport Scoreboards for
different games.To Select the similar
scoreboard picture and send us your idea or changes for this one.
3. After we talking about the all design details and changes ,new
confirmed scoreboard layout will be send
to confirm.
4. For the scoreboard size and Color ,the digit height and color
,all are negotiated.
5. To plus or reduce the digit on the scoreboard,make different
color in one scoreboard,make different
color for cabinet , print Logo on the scoreboard ,all requests are
available in the layout drawing.
Purchase Process
1. Inquiry-Professional quotation by email or telephone. 2. Confirm
the price, lead time, artwork, payment term etc. 3. Send the
Performa Invoice. 4. Customer makes the payment and sends us Bank
receipt. 5. Initial Production Stage-Inform the clients that we
have got the payment, And will make the samples according to your
request, send you photos or Samples to get your approval. After
approval, we inform that we will arrange the production & inform
the estimated time. 6. Middle Production-send photos to show the
production line which you can see your products in . Confirm the
estimated delivery time again. 7. End Production-Mass production
products photos and samples will send to you for approval. You can
also arrange the third party inspection if you need. 8. Finish the
balance payment if the order has .Book the flight or vessel and
ship the goods. Inform the tracking number or send the Documents
for Customer to do Customs Clearance. 9. Order can be say “finish”
when you receive the goods and satisfy with them. 10. Feedback to
us about Quality, Service, Market Feedback & Suggestion. And we can
do better.
Trade Terms
1. Do you accept OEM & ODM order?
Yes! We can produce products according to customers’ design and
samples.
2. What is MOQ?
MOQ can be 1unit.
3. How about the payment terms?
T/T ,Western Union,Paypal in advance .
4. Can I get samples from you?
Yes! Sample could be supplied. But it is not free.
5. What is the warranty?
It is 2 years.
6. What about the price level?
As a professional manufacturer who have been Specializing in the
production of led scoreboard,led gas
price sign,led message sign,led disply for more than 15years, we
are sure that our prices have a great
competitive advantage over the products at the same level.
