Hanging and Light Cabinet Led Electronic Scoreboard For Indoor
Wrestling Game
| PRODUCT INFORMATION |
| Model No. : | LG -EWS-15D300R |
| Dight Height and Color : | 12'' 300mm Height in Yellow and Red Color |
| Display Dimension : | 4.6 ft x 4.9 ft x 4inch ( 1400mm x 1500mm x 100mm ) |
| Operation Type : | PVC Buttons Type Controller Box / Windows Software (Wireless) |
| View Distance : | 1m ~ 300m |
| Application : | Wrestling Sport |
| Frame Color : | Black / other Colors |
| Printed Letters | Sticker in White Color for Any letters |
| Weight : | 20kgs |
| Waterproof : | Outdoor Type |
AFL Scoreboard Descripition
Function : Used for Wrestling Sport and display GAME TIME,HOME / AWAY Scores
, PERIOD , Weight
Specification :
1) Use of the environment: Indoor or Outdoor
2) Brightness: High Level Brightness
3) Height of Characte: 12'' 300mm
4) Display Led Color : Red (Any other kind is Option)
5) Frame Color : Black Color (Any other kind is Option)
Overall Structure :
1) Display usage:
15 Pieces digits , 12 inch character in Red Color
2) Frame : Iron / Steel
3) Faceplate : Display window cover glass board and UV Protection
4) Drainage Outlet at the bottom of the Frame
5) Fans install inside of scoreboard
Technical Norms :
1) Power Supply : 110V ~ 240V
2) Operation Circumstance: -30℃ ~ 65℃ ,0% ~ 95% relative humidity
Operation Type :
1) PVC Buttons Controller Box / Windows Software
2) Hard - wire / Wireless Type
3) Operation Distance : Max 1000Meters.
4) Controller box works by 110V ~ 240V Power (Battery is an Option)
Life Time of Leds : 100000 Hours
Installation : Hanging / Mounting / Custoized Design
Delivery Time : 7days ~ 12days
Warranty : 2 Years
Package Dimension : 1270mm x 1570mm x 160mm (Carton / Wooden Case )
Screen Dimension : 4.6 ' x 4.9 ' x 4''
Function Descripition
Wrestling Scoreboard :
TIME : Minutes / Seconds - 4 Digits to display
SCORE : Each Team with 3 Digits to display 3Games Score
PERIOD : Display number from 1 - 9
Siren : Include . When time is reach to 00 :00 , it will sound for
5 ''
Led Brightness : Option
SCOREBOARD FUNCTION IS CUSTOMIZED ,ANY FUNCTION IS WELCOME !
Packing and Logistics
1. Where do you load the goods?
We offer shipment by sea or by air as requested by the buyer. The
sea port we are used : Shanghai Sea port The airport we are used :
Shanghai Airport
2. What is the lead time ?
Usually, the lead time is 7-10 days. 3. Which logistics company do you cooperate with? Our company cooperates with COSCO, APL, CMA, CSAV, K-LINE, MSC and
etc. For courier, it’s up to buyer’s option. We will give
suggestion according to the time table of the steamers and their
services.
Usual Questions
Q1: What should I do if my Scoreboard is not working properly?
Check the Input Power is with right Volatge. Some countries use
110V and Some Countried use 220V.
If the controller box is without Battery. That must be a power
cable to connect to 110V / 220V plug.
Any other problem can contact with us and take photos for us to
check .
Q2: What is the correct way to store the scoreboard ?
1. Keep out of the reach of children under 8 years.
2. Do not store in dampness and high temperature places.
3. Avoid direct sunlight.
Q3 : What about the maintaince for the scoreboard ?
2 Years Warranty .
Under the condition of not artificial damage, we will send you the
new parts to replace.
