Waterproof Outdoor and Indoor Countdown LED Countdown Timer for
Running Sport
PRODUCT PARAMETER |
| Format : | 88 : 88 | Color : | Red |
| Display Size : | 370mm x 1010mm | Thickness : | 100mm |
| Digit Size : | 12'' 300MM | Housing : | Iron Cabinet |
| Communication1 : | IR Remote | Communication Distance : | IR = 10M |
| Communication2 : | Wire | Communication Distance : | RS232 = 50M |
| Communication3 : | Wireless | Communication Distance : | RF433 =1000M |
| Output Voltage : | 5V | Volatge Input : | 110V ~ 240V AC |
| Brightness : | 5000cd / M2 | Working Temp : | -30℃ ~ +65℃ |
| Viewing Angle : | > 100° | Working Humidity : | 5% - 90% RH |
| Life Span : | 100,000 Hours | Waterproof : | IP65 |
Timer Descripition
Specification :
1) Use of the environment: Outdoor and Indoor
2) Brightness: High Level Brightness
3) Height of Number Option : 6'' / 8'' / 10'' / 12'' / 16'' /
20'' / 24'' / 30'' ect.
4) Number Color Option : Red / Green / Amber / Blue / White
5) Frame Color : Black Color (Any other kind is Option)
Overall Structure :
1) Display Sign Include : Numbers ,Controller , Cabinet / Frame
,Power Supply
2) Frame : Iron / Steel
3) Faceplate : Display window cover glass board and UV Protection
4) Drainage Outlet at the bottom of the Frame
5) Fans install inside of scoreboard
Technical Norms :
1) Power Supply : 110V ~ 240V
2) Operation Circumstance: -30℃ ~ 65℃ ,5% ~ 90% relative humidity
Operation Type :
1) Controller Type : IR Remote / PVC Buttons Controller Box /
Windows Software
2) Communication Type : IR / Hard - wire / Wireless Type
3) Operation Distance : 10m ~ 1200m.
4) Operation Power : Remote with Battery / Controller Box with 110v
~ 240v Power
Life Time of Leds : 100000 Hours
Installation : Hanging / Mounting / Tripod / With wheels / Custoized Design
Delivery Time : 7days ~ 12days
Warranty : 2 Years
Package Dimension : 440mm x 1080mm x 170mm
Dimensions / Function
Dimension:
| Model | Timer Size | Package Dimension |
| 8'' 200mm | 300mm x 700mm x 100mm | 370mm x 770mm x 170mm |
| 10'' 254mm | 350mm x 800mm x 100mm | 420mm x 870mm x 170mm |
| 12'' 300mm | 370mm x 1010mm x 100mm | 440mm x 1080mm x 170mm |
| 16'' 400mm | 610mm x 1320mm x 100mm | 680mm x 1390mm x 170mm |
| 20'' 500mm | 700mm x 1500mm x 100mm | 770mm x 1570mm x 170mm |
| 24'' 600mm | 770mm x 1750mm x 100mm | 840mm x 1820mm x 170mm |
| 30'' 750mm | 920mm x 3140mm x 100mm | 990mm x 3210mm x 170mm |
Timer Function:
1.Display : Hours : Minutes / Minutes : Seconds (Support 12/24 Hour)
2.Count up : Count from zero to 99 hours 59 minutes / 59 minutes 59 seconds
3.Countdown : Count from 99 hours 59 minutes to zero / 99 minutes 59 seconds to zero
4.Stopwatch : seconds and 1/100 of seconds format,zero up to 59:99
5.Interval timer: interval repeating countdown/ count up timer, max
99 rounds
Available Option:
* Install GPS inside as Clock ,then it can search time and Display
AUTO.
* Timer can work by Battery .
* Colon between the digits can be dark and the timer can be used to
display Sports / Game Scores.
* Extra Function to display Temperature.
Components Option
Number Height : 6'' / 8'' / 10'' / 12'' / 16'' / 20'' / 24'' / 30''
Digit Color : Red / Green / Yellow / White / Blue
Number Working Voltage : 5V / 7V / 12V / 16V / 18V
Power Source : Power Supply / Power Adapter / Battery
Power Plug Type : USA / EU / AUS / UK / CN
Controller : IR Remote / Wire Controller box / Wireless Controller
Box / Windows Software
Cabinet / Frame : Aluminium Frame / Iron Cabinet
Installation for Frame / Cabinet : Hanging / Mounting / Tripod (
Suitcase )
Package Material : Protection Material and Carton or Wooden Case
Packing and Logistics
1. Where do you load the goods?
We offer shipment by sea or by air as requested by the buyer. The
sea port we are used : Shanghai Sea port The airport we are used :
Shanghai Airport
2. What is the lead time ?
Usually, the lead time is 7-10 days. 3. Which logistics company do you cooperate with? Our company cooperates with COSCO, APL, CMA, CSAV, K-LINE, MSC and
etc. For courier, it’s up to buyer’s option. We will give
suggestion according to the time table of the steamers and their
services.
Usual Questions
Q1: What should I do if my Scoreboard is not working properly?
Check the Input Power is with right Volatge. Some countries use
110V and Some Countried use 220V.
If the controller box is without Battery. That must be a power
cable to connect to 110V / 220V plug.
Any other problem can contact with us and take photos for us to
check .
Q2: What is the correct way to store the scoreboard ?
1. Keep out of the reach of children under 8 years.
2. Do not store in dampness and high temperature places.
3. Avoid direct sunlight.
Q3 : What about the maintaince for the scoreboard ?
2 Years Warranty .
Under the condition of not artificial damage, we will send you the
new parts to replace.
