High Brightness White Color LED Gas Price Sign with IR Remote for
Outside
PRODUCT PARAMETER |
| Format : | 888.8 (4 x Row) | Color : | White |
| Display Size : | 300mm x 630mm | Thickness : | 100mm |
| Digit Size : | 8'' 200mm | Housing : | Iron Cabinet |
| Communication1 : | IR Remote | Communication Distance : | IR = 10M |
| Communication2 : | Wire | Communication Distance : | RS232 = 50M |
| Communication3 : | Wireless | Communication Distance : | RF433 =1000M |
| Output Voltage : | 5V | Volatge Input : | 110V ~ 240V AC |
| Brightness : | 5000cd / M2 | Working Temp : | -30℃ ~ +65℃ |
| Viewing Angle : | > 100° | Working Humidity : | 5% - 90% RH |
| Life Span : | 100,000 Hours | Waterproof : | IP65 |
Gas Price Sign Descripition
Specification :
1) Use of the environment: Outdoor Gas Station / Service Station
2) Brightness: High Level Brightness
3) Height of Number Option : 6'' / 8'' / 10'' / 12'' / 16'' /
20'' / 24'' / 30'' ect.
4) Number Color Option : Red / Green / Amber / Blue / White
5) Frame Color : Black Color (Any other kind is Option)
Overall Structure :
1) Display Sign Include : Numbers ,Controller , Cabinet / Frame
,Power Supply
2) Frame : Iron / Steel
3) Faceplate : Display window cover glass board and UV Protection
4) Drainage Outlet at the bottom of the Frame
5) Fans install inside of scoreboard
Technical Norms :
1) Power Supply : 110V ~ 240V
2) Operation Circumstance: -30℃ ~ 65℃ ,5% ~ 90% relative humidity
Operation Type :
1) Controller Type : IR Remote / PVC Buttons Controller Box /
Windows Software
2) Communication Type : IR / Hard - wire / Wireless Type
3) Operation Distance : 10m ~ 1200m.
4) Operation Power : Remote with Battery / Controller Box with 110v
~ 240v Power
Life Time of Leds : 100000 Hours
Installation : Hanging / Mounting / Custoized Design
Delivery Time : 7days ~ 12days
Warranty : 2 Years
Package Dimension : 360mm x 700mm x 160mm ( Carton )
Other Standard Dimensions Option
| Model | Gas Price Sign Size | Package Dimension |
| 8'' 200mm | 300mm x 630mm x 100mm | 360mm x 700mm x 160mm |
| 10'' 254mm | 450mm x 950mm x 100mm | 520mm x 1020mm x 160mm |
| 12'' 300mm | 500mm x 1000mm x 100mm | 560mm x 1070mm x 160mm |
| 16'' 400mm | 750mm x 1550mm x 100mm | 820mm x 1620mm x 170mm |
| 20'' 500mm | 800mm x 1600mm x 100mm | 860mm x 1670mm x 170mm |
| 24'' 600mm | 900mm x 2000mm x 100mm | 970mm x 2070mm x 170mm |
| 30'' 750mm | 1150mm x 2400mm x 100mm | 1220mm x 2470mm x 170mm |
Scoreboard Design Details
1. To finish the scoreboard Layout drawing, or can send us the
photo of the scoreboard you need to
produce.
2. On the website we display a lot of Sport Scoreboards for
different games.To Select the similar
scoreboard picture and send us your idea or changes for this one.
3. After we talking about the all design details and changes ,new
confirmed scoreboard layout will be send
to confirm.
4. For the scoreboard size and Color ,the digit height and color
,all are negotiated.
5. To plus or reduce the digit on the scoreboard,make different
color in one scoreboard,make different
color for cabinet , print Logo on the scoreboard ,all requests are
available in the layout drawing.
Packaging & Delivery
Packaging Details :
Air and Express Shipment Packaging : Carton
Sea Shipment Packaging : Wood Case (Free)
OEM Packaging : Customized . Warmly welcome to contact us to talk
more detail.
Delivery Details :
Order Quantity 1Unit ~ 20Units : 7days ~ 10days.
Order Quantity 21Unit ~ 50Units : 10days ~ 15days.
Order Quantity > 50Units : 15days ~ 20days.
Sea Shipment need 25days to arrive.
Air and Express Shipment need 3-5days to arrive.
Cautions when using Scoreboard
1. Confirm the Scoreboard Input Power is 110V or 220V .110V input
power are unable to use by 220V
power socket.
2. Controller box is not waterproof, please avoid to touch the
water.
3. Don’t change any electronic part if there is no any professional
technician.
4. Not for Children under 12Years.
5. Stored in a dry environment, avoid direct sunlight.
6. Avoid heavy objects hit the front galss board.
