Football Sports In Red Color Led Electronic Scoreboard with Folding
Function
| PRODUCT INFORMATION |
| Model No. : | LG-AFL-300W |
| Dight Height and Color : | 12'' 300mm Height in White Color |
| Display Dimension : | 4.4 ft x 9.4 ft x 4inch ( 1350mm x 2850mm x 100mm ) |
| Operation Type : | PVC Buttons Type Controller Box / Windows Software (Wireless) |
| View Distance : | 1m ~ 150m |
| Application : | AFL (Football Sport and Cricket Sport ) |
| Frame Color : | Black / other Colors |
| Printed Letters | Sticker in White Color for Any letters |
| Weight : | 90kgs |
| Waterproof : | Outdoor Type |
AFL Scoreboard Descripition
Function : Display TIME / GOALS / BEHINDS / POINTS / TEAM NAME
Specification :
1) Use of the environment: Indoor or Outdoor
2) Brightness: High Level Brightness
3) Height of Characte: 12'' 300mm
4) Display Led Color : White (Any other kind is Option)
5) Frame Color : Black Color (Any other kind is Option)
Overall Structure :
1) Display usage:
18 Pieces digits , 12 inch character in White Color
2) Frame : Iron / Steel
3) Faceplate : Display window cover glass board and UV Protection
4) Drainage Outlet at the bottom of the Frame
5) Fans install inside of scoreboard
Technical Norms :
1) Power Supply : 110V ~ 240V
2) Operation Circumstance: -30℃ ~ 65℃ ,0% ~ 95% relative humidity
Operation Type :
1) PVC Buttons Controller Box / Windows Software
2) Hard - wire / Wireless Type
3) Operation Distance : Max 1000Meters.
4) Controller box works by 110V ~ 240V Power (Battery is an Option)
5) Controller Buttons for A - Z to enter the Team Name Letters
Life Time of Leds : 100000 Hours
Installation : Hanging / Mounting / Custoized Design
Delivery Time : 7days ~ 12days
Warranty : 2 Years
Package Dimension : 1070mm x 3070mm x 160mm (Carton / Wooden Case )
Screen Dimension : 3.9 ' x 9.8 ' x 4''
AFL Function Descripition
AFL Scoreboard with 2 Modes : Football (Aussie) Mode and Cricket
Mode
TIME : Minutes / Seconds for Football Mode , Hours : Minutes for
Cricket Mode - 4 Digits to display
Footbal Mode Mode :
GOAL - 2 Digits Display score number 00 - 99 ( GOAL + 1 = TOTAL + 6
)
BEHINDS - 2 Digits Display score number 00 - 99 ( BEHINDS + 1 =
TOTAL + 1)
TOTAL - 3 Digits display score number 000 - 999
Cricket Mode Mode :
BATSMEN RUNS - 3 Digits display number 000 - 999
WICKETS - 2 Digits display number 00 - 99
OVERS - 2 Digits display number 00 - 99
BATEMAN TOTAL - 3 Digits display number 000 - 999
CHASING - 3 Digits display number 000 - 999
Team Name : Display Team / Player Name Letters for A - Z
Siren : Include . When time is reach to 00 :00 , it will sound for
5 ''
Led Brightness : Option
SCOREBOARD FUNCTION IS CUSTOMIZED ,ANY FUNCTION IS WELCOME !
About Sample
1. Existing samples can be provided but not for free of charge. 2.
Customized size and layout design are welcome.
3. Sample will be finished about one week.
4. Photos for sample will be sent to confirm befor the shippment.
5. Good after-sale service - any quality problem , we will do our
best to help solve the problem.
6. Large size sample will shipped by air or sea . Sample with small
size and light will send by express.
Scoreboard Design Details
1. To finish the scoreboard Layout drawing, or can send us the
photo of the scoreboard you need to
produce.
2. On the website we display a lot of Sport Scoreboards for
different games.To Select the similar
scoreboard picture and send us your idea or changes for this one.
3. After we talking about the all design details and changes ,new
confirmed scoreboard layout will be send
to confirm.
4. For the scoreboard size and Color ,the digit height and color
,all are negotiated.
5. To plus or reduce the digit on the scoreboard,make different
color in one scoreboard,make different
color for cabinet , print Logo on the scoreboard ,all requests are
available in the layout drawing.
