Customized Design for Size and Low Power Led Electronic Paintball
Scoreboard
| PRODUCT INFORMATION |
| Model No. : | LG - EPS-11D300RGY |
| Dight Height and Color : | 12'' 300mm Height in Red and Yellow and Green Color |
| Display Dimension : | 3.6 ft x 5.6 ft x 4inch ( 1100mm x 1700mm x 100mm ) |
| Operation Type : | PVC Buttons Type Controller Box / Windows Software (Wireless) |
| View Distance : | 1m ~ 350m |
| Application : | Paintball Sport |
| Frame Color : | Black / other Colors |
| Printed Letters | Sticker in White Color for Any letters |
| Weight : | 25kgs |
| Waterproof : | Outdoor Type |
Paintball Scoreboard Descripition
Function : Used for Paintball Sport and display GAME TIME,TIME OUT, 2 Teams
SCORE
Specification :
1) Use of the environment: Indoor or Outdoor
2) Brightness: High Level Brightness
3) Height of Characte: 12'' 300mm
4) Display Led Color : Red / Green / Yellow (Any other kind is
Option)
5) Frame Color : Black Color (Any other kind is Option)
Overall Structure :
1) Display usage:
11 Pieces digits , 12 inch character in 3 Colors
2) Frame : Iron / Steel
3) Faceplate : Display window cover glass board and UV Protection
4) Drainage Outlet at the bottom of the Frame
5) Fans install inside of scoreboard
Technical Norms :
1) Power Supply : 110V ~ 240V
2) Operation Circumstance: -30℃ ~ 65℃ ,0% ~ 95% relative humidity
Operation Type :
1) PVC Buttons Controller Box / Windows Software
2) Hard - wire / Wireless Type
3) Operation Distance : Max 1000Meters.
4) Controller box works by 110V ~ 240V Power (Battery is an Option)
Life Time of Leds : 100000 Hours
Installation : Hanging / Mounting / Custoized Design
Delivery Time : 7days ~ 12days
Warranty : 2 Years
Package Dimension : 1170mm x 1770mm x 160mm (Carton / Wooden Case )
Screen Dimension : 3.6 ' x 5.6 ' x 4''
Function Descripition
Paintball Scoreboard :
GAME TIME : Minutes / Seconds - 4 Digits to display
TIME OUT : Minutes / Seconds - 3 Digits to display
SCORE : Each Team with 2 Digits to display 00 - 99
Siren : Include . When time is reach to 00 :00 , it will sound for
5 ''
Led Brightness : Option
SCOREBOARD FUNCTION IS CUSTOMIZED ,ANY FUNCTION IS WELCOME !
Available Options
- Wireless Remote Control AC System for use with standard numeric
scoreboards
- Wireless Remote Notepad PC controller for use with electronic text
displays & numeric scoreboard
- Mobile trolley on pneumatic wheels
- Rechargeable battery power pack
- Sponsor Panel Graphics
- Pair of 12"/300mm LED 8-10 digit electronic team name inputs
- Pair of 16"/400mm LED 8-10 digit electronic team name
- Pair of 20"/500mm LED 8-10 digit electronic team name inputs
- Pair of 24"/600mm LED 8-10 digit electronic team name inputs
- 12"/300mm LED 21 digit VMS text display for advertising or game
info
- 16"/400mm LED 21 digit VMS text display for advertising or game
info
- 20"/500mm LED 21 digit VMS text display for advertising or game
info
- 24"/600mm LED 21 digit VMS text display for advertising or game
info
About Sample
1. Existing samples can be provided but not for free of charge. 2. Customized size and layout design are welcome.
3. Sample will be finished about one week.
4. Photos for sample will be sent to confirm befor the shippment.
5. Good after-sale service - any quality problem , we will do our
best to help solve the problem.
6. Large size sample will shipped by air or sea . Sample with small
size and light will send by express.
