12'' Inch Digits in Green Color Led Electronic Scoreboard With
Moving Wheels Stand
| PRODUCT INFORMATION |
| Item No. : | LG-ES8D200G |
| Dight Height and Color : | 8'' 200mm Height in Green Color |
| Scoreboard Dimension : | 2.6ft x 3ft (800mm*900mm*90mm) |
| Controller Type : | PVC Controller Box / Windows Software (Wireless) |
| View Distance : | 1m ~ 200m |
| Application : | Multi - Sports |
| Work Temperature : | -20℃ ~ 60℃ |
| Humidity : | 0% - 95% |
Description
Function : Used for Multi - Sport and display GAME TIME,TEAM NAME, 2 Teams
SCORE
Specification :
1) Use of the environment: Indoor or Outdoor
2) Brightness: High Level Brightness
3) Height of Characte: 8'' 200mm
4) Display Led Color : Green (Any other kind is Option)
5) Frame Color : Black Color (Any other kind is Option)
Overall Structure :
1) Display usage: 8 Pieces digits , 8 inch character in Green Color
2) Frame : Iron / Steel
3) Faceplate : Display window cover glass board and UV Protection
4) Drainage Outlet at the bottom of the Frame
5) Fans install inside of scoreboard
Technical Norms :
1) Power Supply : 110V ~ 240V
2) Operation Circumstance: -30℃ ~ 65℃ ,0% ~ 95% relative humidity
Operation Type :
1) PVC Buttons Controller Box / Windows Software
2) Hard - wire / Wireless Type
3) Operation Distance : Max 1000Meters.
4) Controller box works by 110V ~ 240V Power (Battery is an Option)
Life Time of Leds : 100000 Hours
Installation : Hanging / Mounting / Custoized Design
Delivery Time : 7days ~ 12days
Warranty : 2 Years
Package Dimension : 870mm x 970mm x 160mm (Carton)
Screen Dimension : 2.6 ' x 3 ' x 4''
Function
Scoreboard can used forMulti - Sport . The digit height is 200mm
and in Green Color.
Controller Box is PVC material with buttons. Install Wireless
Module and operation Distance is 1m ~ 800m.
1) GAME TIME : 4Digits - MM : SS -00 : 00 ~ 99 : 59
2) TEAM 1 : 2Digits - 00 ~ 99
3) TEAM 2 : 2Digits - 00 ~ 99
4) GAME TIME Type : Countdown / Count up
5) With Siren. When the time to be 00 : 00 or reach to Setup Time,
the siren will sound for 5 Seconds.
About the Scoreboard function ,it is customized . Any request is
welcome.
Scoreboard Design Details
1. To finish the scoreboard Layout drawing, or can send us the
photo of the scoreboard you need to
produce.
2. On the website we display a lot of Sport Scoreboards for
different games.To Select the similar
scoreboard picture and send us your idea or changes for this one.
3. After we talking about the all design details and changes ,new
confirmed scoreboard layout will be send
to confirm.
4. For the scoreboard size and Color ,the digit height and color
,all are negotiated.
5. To plus or reduce the digit on the scoreboard,make different
color in one scoreboard,make different
color for cabinet , print Logo on the scoreboard ,all requests are
available in the layout drawing.
Packing and Logistics
1. Where do you load the goods?
We offer shipment by sea or by air as requested by the buyer. The
sea port we are used : Shanghai Sea port The airport we are used :
Shanghai Airport
2. What is the lead time ?
Usually, the lead time is 7-10 days. 3. Which logistics company do you cooperate with? Our company cooperates with COSCO, APL, CMA, CSAV, K-LINE, MSC and
etc. For courier, it’s up to buyer’s option. We will give
suggestion according to the time table of the steamers and their
services.
Installation Method
For Indoor Scoreboard :
1) Bracket / Bracket with wheels
2) Hanging with Hooks and it is dangly
3) Hanging on the Wall and it is fixed on wall
4) Hanging on the pillar with anchor ear
For Outdoor Scoreboard:
1) Portal Frame
2) Hanging on the Wall and it must be fixed
3) Hanging on the pillar with anchor ear
4) Bracket / Bracket with wheels ( Only for small size )
5) Hanging into Wall and Fixed
Attention Matters:
Dissipate Heat and Drainage – Inform us the installation method in
advance ,we will make
right method on scoreboard.
Maintenance – Easy to do maintance from front or back side .
Stable and stronger Method – Weatherproof
