IP65 Frame Electronic Led Digital Gas Price Signs for Highway
Service Station
PRODUCT PARAMETER |
| Format : | 8.88 with small 8 | Color : | Red |
| Display Size : | 400mm x 1000mm | Thickness : | 100mm |
| Digit Size : | 12'' 300mm 8'' 200mm | Housing : | Iron Cabinet |
| Communication1 : | IR Remote | Communication Distance : | IR = 10M |
| Communication2 : | Wire | Communication Distance : | RS232 = 50M |
| Communication3 : | Wireless | Communication Distance : | RF433 =1000M |
| Output Voltage : | 5V | Volatge Input : | 110V ~ 240V AC |
| Brightness : | 5000cd / M2 | Working Temp : | -30℃ ~ +65℃ |
| Viewing Angle : | > 100° | Working Humidity : | 5% - 90% RH |
| Life Span : | 100,000 Hours | Waterproof : | IP65 |
Gas Price Sign Descripition
Specification :
1) Use of the environment: Outdoor Gas Station / Service Station
2) Brightness: High Level Brightness
3) Height of Number Option : 6'' / 8'' / 10'' / 12'' / 16'' /
20'' / 24'' / 30'' ect.
4) Number Color Option : Red / Green / Amber / Blue / White
5) Frame Color : Black Color (Any other kind is Option)
Overall Structure :
1) Display Sign Include : Numbers ,Controller , Cabinet / Frame
,Power Supply
2) Frame : Iron / Steel
3) Faceplate : Display window cover glass board and UV Protection
4) Drainage Outlet at the bottom of the Frame
5) Fans install inside of scoreboard
Technical Norms :
1) Power Supply : 110V ~ 240V
2) Operation Circumstance: -30℃ ~ 65℃ ,5% ~ 90% relative humidity
Operation Type :
1) Controller Type : IR Remote / PVC Buttons Controller Box /
Windows Software
2) Communication Type : IR / Hard - wire / Wireless Type
3) Operation Distance : 10m ~ 1200m.
4) Operation Power : Remote with Battery / Controller Box with 110v
~ 240v Power
Life Time of Leds : 100000 Hours
Installation : Hanging / Mounting / Custoized Design
Delivery Time : 7days ~ 12days
Warranty : 2 Years
Package Dimension : 460mm x 1070mm x 160mm
Other Standard Dimensions Option
| Model | Gas Price Sign Size | Package Dimension |
| 8'' 200mm | 300mm x 630mm x 100mm | 360mm x 700mm x 160mm |
| 10'' 254mm | 720mm x 1470mm x 170mm | 410mm x 820mm x 160mm |
| 12'' 300mm | 400mm x 1000mm x 100mm | 460mm x 1070mm x 160mm |
| 16'' 400mm | 580mm x 1500mm x 100mm | 650mm x 1570mm x 170mm |
| 20'' 500mm | 650mm x 1400mm x 100mm | 720mm x 1470mm x 170mm |
| 24'' 600mm | 700mm x 1650mm x 100mm | 770mm x 1720mm x 170mm |
| 30'' 750mm | 850mm x 2000mm x 100mm | 920mm x 2070mm x 170mm |
Features
1. Linger devote to design the different sports of customized
scoreboard, any kind of digit height and digit color is made for
different scoreboard.
2. Scoreboard controller type can be with cable or wireless type.
3. The brightness is enough for outside in day and night.
4. Scoreboard with Iron waterproof cabinet and prevent the impact.
5. The front face is acrylic glass board to protect digits and the
acrylic glass board is UV Protection type.
Usual Questions
Q1: What should I do if my Scoreboard is not working properly?
Check the Input Power is with right Volatge. Some countries use
110V and Some Countried use 220V.
If the controller box is without Battery. That must be a power
cable to connect to 110V / 220V plug.
Any other problem can contact with us and take photos for us to
check .
Q2: What is the correct way to store the scoreboard ?
1. Keep out of the reach of children under 8 years.
2. Do not store in dampness and high temperature places.
3. Avoid direct sunlight.
Q3 : What about the maintaince for the scoreboard ?
2 Years Warranty .
Under the condition of not artificial damage, we will send you the
new parts to replace.
Installation Method
For Indoor Scoreboard :
1) Bracket / Bracket with wheels
2) Hanging with Hooks and it is dangly
3) Hanging on the Wall and it is fixed on wall
4) Hanging on the pillar with anchor ear
For Outdoor Scoreboard:
1) Portal Frame
2) Hanging on the Wall and it must be fixed
3) Hanging on the pillar with anchor ear
4) Bracket / Bracket with wheels ( Only for small size )
5) Hanging into Wall and Fixed
Attention Matters:
Dissipate Heat and Drainage - Inform us the installation method in
advance ,we will make
right method on scoreboard.
Maintenance - Easy to do maintance from front or back side .
Stable and stronger Method - Weatherproof
